KNUTH CNC FLAT BED LATHE MACHINE STARCHIP 560 - ATCL

Features The enclosed work space is easily accessible through a large sliding door A powerful 15 kW headstock motor delivers high torque across the entire speed range Hydraulic 250 mm 3-jaw chuck with through-hole Automatic central lubrication system ensures reliable lubrication of guideways Hinged belt conveyor and high-performance coolant system included in standard equipment Proven record: Future-proof: the Siemens 828 D Basic control meets all requirements for advanced control technology Easy, dialog-guided user interface Complete bandwidth of technology cycles High performance and precision

Category: CNC Machinery

SKU: CNG

KNUTH CNC FLAT BED LATHE MACHINE STARCHIP 560

Working area
Workpiece length (max.) 500 mm
Maximum workpiece weight 200 - 500 kg
Angle of slant bed 45 deg
Turning-Ø over bed (max.) 560 mm
Turning-Ø over support 350 mm
Travels
Travel X-axis 200 mm
Travel Z-axis 560 mm
Headstock
Spindle speed 4500 r/min
Spindle mount ISO A2-6
Lathe chuck diameter 250 mm
Spindle bore 65 mm
Spindle bore with draw tube 50 mm
Rapid feed
Rapid feed X-axis 30000 mm/min
Rapid feed Z-axis 30000 mm/min
Tooling
Number of tool stations 12 Pieces
Tool shank dimensions 25x25 mm
Diameter 40 mm
Accuracies
Positioning accuracy X-axis
± 0.008 mm
Positioning accuracy Z-axis ± 0.008 mm
Repeatability X-axis ± 0.004 mm
Repeatability Z-axis ± 0.004 mm
Tailstock
Tailstock taper MT 5
Tailstock quill stroke 450 mm
Drive capacity
Motor rating main drive 15 kW
Main drive, continuous load 11 kW
Motor rating X-axis 1.8kW
Motor rating Z-axis 1.8kW
Measures and weights
Overall dimensions (length x width x height) 2.75x1.86x1.9 m
Weight 3900 kg
STANDARD EQUIPMENTS:
Siemens 828D control
12-station turret
electronic hand-wheel
hydr. 3-jaw chuck Ø 250 mm
auto bar feeder interface
chip conveyor chain type
programable tailstock
coolant system flush gun
air gun
coolant system
automatic central lubrication
heat exchanger control cabinet
work lamp
operational health status indicator
operator instructions
Siemens 828 D Basic
Compact, rugged and maintenance-free operator-panel CNC with dedicated system software for turning, milling and grinding technologies
High-quality, rugged, magnesium die-cast operator panels with degree of protection IP65
Maintenance-free operator panel front, e.g. no fan, battery or hard disk
Highest machining precision with 80-bit NANOFPaccuracy
New user interface SINUMERIK Operate – same look and feel as SINUMERIK 840D sl
ShopTurn/ShopMill (option): Very fast programming time in the production of individual parts and small batches
Advanced Surface: Innovative, high-performance CNC functions provide top quality of workpiece surface with minimum machining times
SINUMERIK MDynamics with the new Advanced Surface feature: for perfect part surfaces and shortest machining times in mold making applications
programGUIDE: fastest machining time and maximum flexibility for large series productions
Unique spectrum of technology cycles – ranging from the machining of any turning and milling contour with residual material detection to in-process measurements
G-Tech is a grinding package with an extensive scope of CNC functions ranging from the low-cost entry-level model up to highly productive machines
Animated Elements: unique operation and programming assistance with animated sequences
modern data transfer options via USB stick, CF card and network (Ethernet)
SINUMERIK Integrate for production Access MyMachine /Ethernet permits remote diagnostics from anywhere in the world
Easy Message: Integrated mobile radio modem for optimum process monitoring and maximum machine availability via text messages (SMS)
Easy Extend: Flexible handling of machine units, e.g. an A axis/parts machine
Maintenance scheduler: Signaling of pending maintenance tasks in accordance with specified maintenance intervals
Functions
Operator panel variants for horizontal or vertical operator panel housings
Proximity/clearance sensor for smart display control
Integrated QWERTY full CNC keyboard with short-stroke keys
Additional Ethernet interface at the rear of the CNC for connection to factory network
Additional USB interface at the rear of the CNC for machine control panel
Integrated PLC based on the SIMATIC S7-200 command set with ladder logic programming
I/O interface based on PROFINET for the connection of PLC I/O devices and a machine control panel
Up to 5 axes/spindles
1 analog spindle
1 machining channel/mode group
Integrated tool management with tool life monitoring
Configurable user screens with SINUMERIK Integrate for engineering Run MyScreens (Easy Screen)
SINUMERIK Integrate for engineering Run MyRobot /EasyConnect for simple interfacing of robots and handling systems
Integrated data archiving procedure for simple data updates
